| MODE | M53S |
| Max.Size of wokr-piece | 1240mm*2445mm*200mm |
| Machine construction | Heavy duty overall welding heat treatment bed |
| Max return speed | 60000-80000mm/min |
| Max processing speed | 20000-25000mm/min |
| Transmission | High precision helical rack Imported high precision grinding ball screw |
| Guide rail | Imported straight square type high precision dustproof guide rail |
| Work holding | Double vacuum adsorption |
| Voltage | AC380V±10%,50/60Hz |
| Tools setting system | High precision automatic tool srtting instrument |
| Electrical components | CHNT/schneider |
| Cable | Highly flexible Cable |
| Driving system | Servo Motor |
| Frequencu converter | Hig performance high frequency anti-jamming inverter |
| Auto-feedling system | Suction cup automatic loading and unloading platform |
| Random instrument | Toolbox(1 set) |
| Outline dimension | 3900mm*2220mm*2400mm |
| *The above machine specifications are for reference only, and are subject to the actual order. Customization is available according to customer needs. | |
